D-3
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Appendix D Chassis and Module LEDs
Supervisor Module LEDs
MGMT ETH Green The management port is operational.
Amber The management port link has been disabled through the software.
Flashing
Amber
The management port link is bad and has been disabled due to a hardware
failure.
Off The module has not detected a signal.
LINK Green The module has detected a link.
Off The module does not detect a link.
ACT Flashing green The module is transmitting or receiving.
Off The module is not transmitting or receiving.
ACT LOG FLASH
(Supervisor 1)
LOG FLASH
(Supervisor 2 and 2E)
Green The log flash CompactFlash or USB disk is being accessed. Do not remove
the media until the LED is off.
Off The expansion flash CompactFlash or USB disk is not being accessed. You
can remove the media while this LED is off.
ACT EXPANSION FLASH
(Supervisor 1)
Slot 0
(Supervisor 2 and 2E)
Green The expansion flash CompactFlash or USB disk is being accessed. Do not
remove the media until the LED is off.
Off The log flash CompactFlash or USB disk is not being accessed. You can
remove the media while this LED is off.
CMP MGMT ETH
(Supervisor 1 module only)
Green The management port is operational.
Amber The management port link has been disabled through the software.
Flashing amber The management port link is bad and has been disabled due to a hardware
failure.
Off The module does not detect a signal.
CMP STATUS
(Supervisor 1 module only)
Green All diagnostics pass. The CMP is operational (normal initialization
sequence).
Amber Sufficient power is not available for all modules.
Flashing amber The diagnostic test has failed.
or
The CMP is not operational because a fault has occurred during the
initialization sequence.
Red The module has detected a slot ID parity error.
Off The CMP is not receiving power.
LINK
(Supervisor 1 module only)
Green The module has detected a link.
Off The module has not detected a link.
ACT
(Supervisor 1 module only)
Flashing green The module is transmitting or receiving.
Off The module is not transmitting or receiving.
Table D-2 Supervisor Module LEDs (continued)
LED Status Description
