Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Appendix E Repacking the Cisco Nexus 7000 Series Switch for Shipment
Repacking the System Components
Step 28 Place the power supply box in the non raised area beside the chassis as shown in View A in Figure E-33
on page E-50.
Step 29 Place the three-segment divider in the non-raised area above the power supply box as shown in View A
in Figure E-33.
Step 30 Remove each of the two bottom-support rails from the rack or cabinet by loosening the eight screws that
secure each of them to the vertical mounting rails on the rack or cabinet.
Step 31 Reassemble the accessory kit by placing the following components in the accessory kit box:
Bottom-support rails (two) and mounting screws (34)
Console connector cables and adapters
Ground lugs (do not include the ground cable) and mounting screws (two per lug)
Power cables (one or two for each 6-kW power supply unit)
Step 32 Place one J-box half on the bottom pallet along two sides of the pallet as shown in View A of
Figure E-33.
Step 33 Place the other J-box half on the other two sides as shown in View A of Figure E-33.
Step 34 Connect the two J-box pieces with six corro clips (three on each seam) as shown in View A of
Figure E-33.
Step 35 If your system included the optional front door and air intake frame, pack those items in their original
packing materials and place them in the open area above the power supply box.
Step 36 Place the corrugated cardboard lid on top of the package as shown in View B of Figure E-33.
Step 37 Place each of the four edge protectors on one of the top edges of the lid (see View C of Figure E-33).
Step 38 Secure the package to the pallet using at least four packing straps (two in one direction and two in the
other direction) as shown in View C of Figure E-33.
1 Power supply box. 6 Insert accessory kit, cable management frame kit, and the optional
front door and air intake frame kit.
2 Polyethylene cushion. 7 Corrugated cardboard lid.
3 Three-segment divider. 8 Edge protectors.
4 Two J-box halves. 9 Packing straps.
5 Corro clips.
