4-6
Cisco SCE8000 GBE Installation and Configuration Guide
Chapter 4 Installing the Cisco SCE 8000 Chassis
AC-Powered Systems
– For North America, the circuit breaker should be rated at 20A.
– For everywhere else, the circuit breaker should be sized according to the power supply input
rating and local or national code requirements.
• AC power receptacles used to plug in the chassis must be the grounding type. The grounding
conductors that connect to the receptacles should connect to protective earth ground at the service
equipment.
Warning This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the
absence of a suitably installed ground conductor. Contact the appropriate electrical inspection
authority or an electrician if you are uncertain that suitable grounding is available.
Statement 1024
Note The plug-socket combination must be accessible at all times because it serves as the main disconnecting
device.
Note This product requires short-circuit (overcurrent) protection, to be provided as part of the building
installation. Install only in accordance with national and local wiring regulations.
Table 4-3 lists the Cisco SCE 8000 AC power specifications.
Table 4-3 Cisco SCE 8000 AC Power Specifications
Specification Acceptable Range
PWR-2700-AC/4 minimum capability 1350 W output (1650 W input)
AC-input power consumption
• Single Cisco SCE 8000-SCM-E module:
1000 W (8.3 A @ 120 VAC, 4.5 A @ 220 VAC)
• Dual Cisco SCE 8000-SCM-E modules:
1600 W (13.3 A @ 120 VAC, 7.27 A @ 220 VAC)
AC-input voltage rating Low-line (120 VAC nominal)-85 VAC (min) to 132 VAC (max)
High-line (230 VAC nominal)-170 VAC (min) to 264 VAC (max)
AC-input current rating 16 A maximum at 120 VAC
16 A maximum at 230 VAC
AC-fusing requirements For North America, the circuit breaker should be rated at 20 A.
For everywhere else, the circuit breaker should be sized according to the
input current rating and local or national code requirements.
AC-input frequency rating 50/60 Hz (nominal) (±3% for full range)
