SNMP
Model Object IDs
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 276
19
Model Object IDs
The following are the switch model Object IDs (OIDs):
Configuring SNMP Engine ID
The Engine ID is only used by SNMPv3 entities to uniquely identify them. An SNMP
agent is considered an authoritative SNMP engine. This means that the agent
responds to incoming messages (Get, GetNext, GetBulk, Set), and sends trap
messages to a manager.
Each SNMP agent maintains local information that is used in SNMPv3 message
exchanges. The default SNMP Engine ID is comprised of the enterprise number
and the default MAC address. The SNMP Engine ID must be unique for the
administrative domain, so that no two devices in a network have the same Engine
ID.
Local information is stored in four MIB variables that are read-only (snmpEngineId,
snmpEngineBoots, snmpEngineTime, and snmpEngineMaxMessageSize).
Model Object ID
SF220-24 1.3.6.1.4.1.9.6.1.84.24.1
SF220-24P 1.3.6.1.4.1.9.6.1.84.24.2
SF220-48 1.3.6.1.4.1.9.6.1.84.48.1
SF220-48 1.3.6.1.4.1.9.6.1.84.48.2
SG220-26 1.3.6.1.4.1.9.6.1.84.26.1
SG220-26P 1.3.6.1.4.1.9.6.1.84.26.2
SG220-50 1.3.6.1.4.1.9.6.1.84.50.1
SG220-50P 1.3.6.1.4.1.9.6.1.84.50.2
SG220-28 1.3.6.1.4.1.9.6.1.84.28.5
SG220-28MP 1.3.6.1.4.1.9.6.1.84.28.3
SG220-52 1.3.6.1.4.1.9.6.1.84.52.5

Cisco SG220-26 Specifications

General

Model	SG220-26
Category	Switch
Ports	24 x 10/100/1000 + 2 x Gigabit SFP
Switching Capacity	52 Gbps
Forwarding Rate	38.69 Mpps
Layer	Layer 2
PoE	No
Mounting	Rack-mountable
MAC Address Table Size	8K entries
Power Supply	Internal
Management	Web-based
Jumbo Frame Support	9216 bytes
Operating Temperature	0°C to 40°C (32° to 104°F)
Storage Temperature	-20°C to 70°C (-4° to 158°F)
Humidity	10% to 90%, non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
