Administration: Discovery
Configuring LLDP
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 90
8
STEP 4 Click Apply. The LLDP MED port settings are modified, and the Running
Configuration is updated.
STEP 5 Click LLDP Local Information Detail to see the details of the LLDP and LLDP MED
TLVs sent to the neighbor.
Viewing LLDP Port Status
The LLDP Port Status page displays the LLDP global information, as well as the
LLDP status per port.
To view the LLDP port status:
STEP 1 Click Administration > Discovery LLDP > LLDP Port Status.
The following fields are displayed:
• Chassis ID Subtype—Type of chassis ID (for example, MAC address).
• Chassis ID—Identifier of chassis. Where the chassis ID subtype is a MAC
address, the MAC address of the switch is displayed.
• System Name—Name of the switch.
• System Description—Description of the switch (in alphanumeric format).
• Supported System Capabilities—Primary functions of the device, such as
Bridge, WLAN AP, or Router.
• Enabled System Capabilities—Primary enabled functions of the device.
• Port ID Subtype—Type of the port identifier that is shown.
The following LLDP information for each port is displayed:
• Interface—Port identifier.
• LLDP Status—LLDP publishing option.
• LLDP MED Status—Where LLDP MED is enabled or disabled on the port.
• Local PoE—(Only applicable for PoE models) Local PoE information
advertised.
• Remote PoE—(Only applicable for PoE models) PoE information advertised
by the neighbor.
