Administration: General Information
Configuring Console Settings
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 64
5
Configuring Console Settings
Use the Console Settings page to configure the console port Baud rate. The
default console port settings are displayed as follows:
• 9,600 bits per second
• 8 data bits
• no parity
• 1 stop bit
• no flow control
To change the console port Baud rate:
STEP 1 Click Administration > Console Settings.
STEP 2 Select a value from the Console Port Baud Rate drop-down menu. The available
values are 2400, 4800, 9600, 19200, 38400, 57600, and 115200 Bit/sec.
STEP 3 Click Apply. The console port Baud rate is defined, and the Running Configuration
is updated.
Rebooting the Switch
Some configuration changes require the switch to be rebooted before they take
effect. However, rebooting the switch will delete the Running Configuration, so it is
critical that the Running Configuration is saved to the Startup Configuration before
the switch is rebooted. Clicking Apply does not save the configuration to the
Startup Configuration.
You can save the Running Configuration on the Administration > Save/Copy
Configuration page or click Save at the top of the window.
To reboot the switch:
STEP 1 Click Administration > Reboot.
STEP 2 Click Reboot to reboot the switch. Because any unsaved information in the
Running Configuration is discarded when the switch is rebooted, you must click
