Cisco SG220-26 Administration Guide

Administration: System Logs
Viewing Memory Logs
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 41
3
Viewing Flash Memory Logs
The Flash Memory page displays the messages that are stored in flash memory in
chronological order. The minimum severity for logging is configured on the Log
Settings page. Flash logs remain when the switch is rebooted. You can clear the
logs manually.
To view flash logs:
STEP 1 Click Status and Statistics > View Log > Flash Memory.
The following fields are displayed:
• Log Index—Log entry number.
• Log Time—Time when message was generated.
• Severity—Event severity.
• Description—Message text describing the event.
STEP 2 Click Clear Logs to clear the log messages.

Cisco SG220-26 Specifications

General

Model	SG220-26
Category	Switch
Ports	24 x 10/100/1000 + 2 x Gigabit SFP
Switching Capacity	52 Gbps
Forwarding Rate	38.69 Mpps
Layer	Layer 2
PoE	No
Mounting	Rack-mountable
MAC Address Table Size	8K entries
Power Supply	Internal
Management	Web-based
Jumbo Frame Support	9216 bytes
Operating Temperature	0°C to 40°C (32° to 104°F)
Storage Temperature	-20°C to 70°C (-4° to 158°F)
Humidity	10% to 90%, non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
