Cisco SG220-26 Administration Guide

Administration: Time Settings
Time Range
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 74
6
• Periodic Starting Time—Enter the date and time that the Time Range begins
on a periodic basis.
• Periodic Ending Time—Enter the date and time that the Time Range ends on
a periodic basis.
STEP 5 Click Apply.
STEP 6 Click Time Range to access the Absolute Time Range.

Cisco SG220-26 Specifications

General

Model	SG220-26
Category	Switch
Ports	24 x 10/100/1000 + 2 x Gigabit SFP
Switching Capacity	52 Gbps
Forwarding Rate	38.69 Mpps
Layer	Layer 2
PoE	No
Mounting	Rack-mountable
MAC Address Table Size	8K entries
Power Supply	Internal
Management	Web-based
Jumbo Frame Support	9216 bytes
Operating Temperature	0°C to 40°C (32° to 104°F)
Storage Temperature	-20°C to 70°C (-4° to 158°F)
Humidity	10% to 90%, non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
