Chapter 4 Installation and Maintenance
Installing the SCE 2000 Platform
Figure 4-10 Sliding the SCE Platform into the Rack
Step 4
While keeping the brackets flush against the posts or mounting strips, align the holes in the brackets with
the holes on the rack or mounting strip.
Figure 4-11 Securing the SCE Platform to the Rack
Step 5
For each bracket, insert and tighten two appropriate screws to the rack.
