Cisco SCE 2000 4xGBE Installation and Configuration Guide
OL-7824-06
Chapter 5 Connecting the Management Interfaces and Performing Initial System Configuration
Initial System Configuration
EXAMPLE:
Following is a sample DNS configuration dialog. The default domain name is pcube.com, and the IP
address of the Domain Name Server is 10.1.1.230.
Would you like to enter the DNS configuration menu? [no]: yEnable IP DNS-based hostname
translation? [yes]:
Enter default domain name []: pcube.comEnter Primary DNS IP address: 10.1.1.230Would you
like to add another Name Server? [no]:
Step 6: How to Configure the RDR Formatter Destination
The SCE 2000 passes Raw Data Records (RDRs) to an external collection system via the
RDR-Formatter. In order for the data to reach the correct location, the IP address of the external
collection system and its port number must be configured.
SUMMARY STEPS
1. Enter the RDR formatter configuration menu.
2. Type the IP address of the RDR-formatter destination and press Enter.
3. Type the TCP port number of the RDR-formatter destination and press Enter.
DETAILED STEPS
Step 1 Enter the RDR formatter configuration menu.
Would you like to enter the RDR-formatter configuration menu? [no]: y
Type yand press Enter.
The RDR-formatter destination dialog begins.
Step 2 Type the IP address of the RDR-formatter destination and press Enter.
Enter RDR-formatter destination’s IP address:
Note that there is no default for this parameter.
Step 3 Type the TCP port number of the RDR-formatter destination and press Enter.
Note that there is no default for this parameter.
Enter RDR-formatter destination’s TCP port number:
EXAMPLE:
Following is a sample RDR-formatter configuration dialog, assigning the IP address and TCP port
number.
Would you like to enter the RDR-formatter configuration menu? [no]: yEnter RDR-formatter
destination’s IP address: 10.1.1.230Enter RDR-formatter destination’s TCP port number:
33000
Step 7: Configuring Access Control Lists (ACLs)
The SCE 2000 can be configured with Access Control Lists (ACLs), which are used to permit or deny
incoming connections on any of the management interfaces.

Cisco SGE2000 Specifications

General

Jumbo Frame Support	9KB
VLANs	Up to 256
Management	Web-based, SNMP, CLI
Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1D, 802.1Q, 802.1p, 802.1w
Dimensions	440 x 44 x 257 mm
Power Supply	100 to 240V AC, 50-60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 90% non-condensing
Weight	3.2 kg
