SNMP
Group Profile
SPS208G/SPS224G4/SPS2024 Service Provider Switches User Guide 222
12
Group Profile
The
Group Profile
Screen
provides information for creating SNMP groups and
assigning SNMP access control privileges to SNMP groups. Groups allow network
managers to assign access rights to specific device features, or features aspects.
To create and configure SNMP group profiles:
STEP 1 Click SNMP > Group Profile. The
Group Profile Screen
opens.
Figure 101 SNMP Group Profile Screen
The
Group Profile
Screen
is divided into two areas:
• Group Parameters
• Group Table
The Group Parameters area contains the following fields:
• Group Name — Indicates the user-defined group to which access control
rules are applied. The field range is up to 30 characters.
