VLAN Management
Create VLAN
SPS208G/SPS224G4/SPS2024 Service Provider Switches User Guide 52
4
The Single VLAN area contains the following fields:
• VLAN ID — Indicates the ID number of the VLAN being configured. The
possible range is 2-4093 (for SPS-208 and SPS-224G4) or 2-4094 (for SPS-
2024)2-40934094. Up to 255 VLANs can be created. This field is used to add
VLANs one at a time. To add the defined VLAN ID number, press Add.
• VLAN Name — Defines the VLAN name.
The VLAN Range area contains the following field:
• VLAN Range — Indicates a range of VLANs (up to 20 at a single time) being
configured. To add the defined range of VLAN ID numbers, press Add
Range.
In addition to fields described previously, the VLAN Table area contains the
following fields:
• Status — Indicates the VLAN type. The possible field values are:
-
Static
— Indicates the VLAN is user-defined.
-
Default
— Indicates the VLAN is the default VLAN.
• To t a l E x i s t i n g V L A N s — Indicates the total number of defined VLANs on the
device.
STEP 2 Define the VLAN ID and VLAN Name and click Add, or define the VLAN Range and
click Add Range. The VLAN details appear in the VLAN Table and the device is
updated.
To delete a VLAN from the device:
STEP 3 In the VLAN Table, select the VLAN.
STEP 4 Click Delete. The selected VLAN is deleted from the device.
