Cisco Telepresence MX800 User Manual

18
D1534504 User Guide
Cisco TelePresence
Produced: November 2016 for CE 8.2
All contents © 2010–2016
Cisco Systems, Inc. All rights reserved.
This feature allows you to be in a call
with two parties, but one at a time
only.
You may swap whom you are in call
with, and you may connect the two
together, while you leave the call.
About Consult and Transfer
Locate
whom to
call in the
usual way.
Assume that
you are in a
call. Tap Hold.
Tap + Place New Call or tap
Resume to go back to the one
you were in call with (to undo
your action).
Place the call in the
usual way.
You are now in the new
call while the one you
were in call with still is
on hold.
Tap Swap to
go between
the two parties
and Transfer
to connect the
two together, while you leave the call.
Consult and Transfer
Transfer Call

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
