23
D1534504 User Guide
Cisco TelePresence
Produced: November 2016 for CE 8.2
All contents © 2010–2016
Cisco Systems, Inc. All rights reserved.
Availability
Enable Do Not Disturb
Your system can be set to not
respond to incoming calls. You may,
however, use it to call others as
much as you want.
Your video support team may have
set a time-out on this feature,
after which the system will return
to respond to incoming calls as
usual. Default time-out setting is 60
minutes.
About Do Not Disturb
Tap Hide to remove the message that appears, telling you
that Do not disturb has been activated.
Tap the eld in the upper left corner. Tap Do not Disturb, as shown. The feature will now be
active.
To deactivate the feature, repeat the procedure.
