Cisco Telepresence MX800 User Manual

27
D1534504 User Guide
Cisco TelePresence
Produced: November 2016 for CE 8.2
All contents © 2010–2016
Cisco Systems, Inc. All rights reserved.
Assume that you are already in a call.
If you then receive another incoming
call, you will have the following
options:
•
You may decline the call and
continue with what you were
doing.
•
You may put the current call on
hold and accept the new call. At
any time you may swap between
the two.
•
You may transfer the incoming call
to someone else, including the
one you were talking to.
•
You may, after putting the
incoming call on hold, later decide
to merge this call with the existing
(optional feature).
•
You may merge the incoming
call directly with the ongoing call
(ACCEPT & MERGE). This applies
to MultiSite equipped systems only.
Add: Provided that
your system supports
it: Accept the incoming
call and merge it with
the ongoing call.
Some systems may
accept that you merge
the incoming call with
the existing, but as an
audio-only call.
You may be prompted
to put the current call
(or group of calls) on
hold before merging
can take place.
Decline the incoming call
and carry on as you have
been doing.
Accept the incoming
call, while holding the
current call or group of
calls.
Accept the incoming call,
while ending the current call
or group of calls.
The identity of the new
incoming call is stated
here.
About Adding Incoming
Calls
Conference Calls with Multiple Participants
Add Incoming Call to Existing Call

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
