47
D1534504 User Guide
Cisco TelePresence
Produced: November 2016 for CE 8.2
All contents © 2010–2016
Cisco Systems, Inc. All rights reserved.
The Recents lists the received,
placed and missed calls since the
last time the list was cleared.
Tap an entry and you may:
Call the entry by tapping CALL.
Add the entry to an ongoing call
(optional).
Add the entry to Favorites.
Edit the entry information and then
place the call.
Change the call rate settings.
Remove the entry from the list.
Clear the entire list.
About Recents
Call Recents
Tap
Contacts, if
needed.
Scroll to
get to
the top of
the list, if
needed.
Tap Clear Recents.
Clearing the entire Recents list:
Select an entry in the
Recents list by tapping it.
Then tap More
( ).
Removing a single entry:
For privacy reasons you may want to
remove an entry from the Recents list or
clear the entire list.
The same persons may have called
you (or you called them) several times.
Each such call will create an entry in the
Recents list.
If you choose to remove a single entry in
the list, any other instances of that entry
will not be removed from the list.
Tap
Contacts.
Tap Recents.
Gaining access to the Recents list:
Contacts
Tap Remove from
Recents to remove
the entry. You will be
prompted to conrm
your intentions.
