1487464659 2064960537 ASR9K-PE2 est 26.26.26.26 2 L2TPV3_CLASS
This table describes the significant fields shown in the display.
Table 5: show l2tp tunnel Field Descriptions
DescriptionField
Local session ID.LocTunID
Remote session ID.RemTunID
Remote name of the session.Remote Name
State of the session.State
Remote address of the session.Remote Address
Session port.Port
Number of sessions.Sessions
L2TP class name.L2TP
The following sample output is from the show l2tp tunnel detail command:
RP/0/0/CPU0:router(config-l2vpn-encap-mpls)# show l2tp tunnel detail
Tue Jun 10 12:47:36.638 UTC
Tunnel id 1487464659 is up, remote id is 2064960537, 2 active sessions
Remotely initiated tunnel
Tunnel state is established, time since change 4d19h
Tunnel transport is IP (115)
Remote tunnel name is ASR9K-PE2
Internet Address 26.26.26.26, port 0
Local tunnel name is PRABHRAM-PE1
Internet Address 25.25.25.25, port 0
VRF table id is 0xe0000000
Tunnel group id
L2TP class for tunnel is L2TPV3_CLASS
Control Ns 4178, Nr 4181
Local RWS 512 (default), Remote RWS 512
Control channel Congestion Control is disabled
Tunnel PMTU checking disabled
Retransmission time 1, max 1 seconds
Unsent queuesize 0, max 0
Resend queuesize 0, max 1
Total resends 0, ZLB ACKs sent 4177
Total out-of-order dropped pkts 0
Total out-of-order reorder pkts 0
Total peer authentication failures 0
Current no session pak queue check 0 of 5
Retransmit time distribution: 0 0 0 0 0 0 0 0 0
Control message authentication is disabled
Related Commands
DescriptionCommand
Displays information about L2TP sessions.show l2tp session, on page 90
Cisco IOS XR Virtual Private Network Command Reference for the Cisco XR 12000 Series Router, Release 4.3.x
94 OL-28460-01
Virtual Private Network Commands
show l2tp tunnel
