Operation Panel
2-57 CL-S6621
(b) Service Mode menu table
Submenu Name Value Description
Head Check None [PAUSE]: Checks the number of defective
thermal elements and prints it. If no defective
thermal element is found, “0” will be printed.
Example: Bad head element: 0 dot(s)
[STOP]: Nothing is printed.
ROM Check None [PAUSE]: Performs ROM checksum test, and
prints the check result (OK or NG) and the
checksum value.
Example: PROGRM ROM OK 4F4E
[STOP]: Nothing is printed.
RAM Check None [PAUSE]: Performs RAM capacity check and
prints the check result.
Example: RAM OK 32768K
[STOP]: Nothing is printed.
Print Counter None [PAUSE]: Prints the total printed length
accumulated from when the printer is firstly
used.
Example: Length 1234.5Km
[STOP]: Nothing is printed.
Service Counter None [PAUSE]: Prints the service counter length in
Km accumulated from when it was reset last
time.
Example: Length 0123.4Km
Clear Service Counter ?
Yes=(PAUSE) No=(STOP)
To clear the service counter, press the
[PAUSE] key again. To quit, press the
[STOP] key.
[STOP]: Nothing is printed.
Cut Counter None [PAUSE]: Prints the cut counter value
accumulated from when it was reset last time.
Example: Count 10
Clear Cut Counter ?
Yes=(PAUSE) No=(STOP)
To clear the cut counter, press the
[PAUSE] key again. To quit, press the
[STOP] key.
[STOP]: Nothing is printed.
To Next Page
