2-3. Operation Panel
CLP-621 & CLP-631 2-42 2-42
[Procedure to enter Factory/Service Mode] [Procedure to enter Factory/Service Mode]
1. Set media. 1. Set media.
2. While pressing and holding all keys, turn on the power. (ALL keys + [POWER]) 2. While pressing and holding all keys, turn on the power. (ALL keys + [POWER])
The printer enters Factory/Service mode. The PRINT LED and CONDITION LED light
up and the following message is printed on media.
The printer enters Factory/Service mode. The PRINT LED and CONDITION LED light
up and the following message is printed on media.
3. Press the [STOP] key to skip to the next message. 3. Press the [STOP] key to skip to the next message.
Then, the following message is printed. Then, the following message is printed.
4. Press the [STOP] key to skip to the next message. 4. Press the [STOP] key to skip to the next message.
Then, the following message is printed. Then, the following message is printed.
5. Press the [PAUSE] key to enter the menu settings mode. 5. Press the [PAUSE] key to enter the menu settings mode.
Then, the following top menu is printed. Then, the following top menu is printed.
• To enter the Factory Mode menu, proceed to the next step 6. • To enter the Factory Mode menu, proceed to the next step 6.
• To skip to the next top menu (Service Mode menu), press the [STOP] key. See step
7.
• To skip to the next top menu (Service Mode menu), press the [STOP] key. See step
7.
• To return to the previous one, press the [MODE] key. • To return to the previous one, press the [MODE] key.
6. Press the [PAUSE] key to enter the submenus. 6. Press the [PAUSE] key to enter the submenus.
* The following submenus under the Factory Mode menu will be printed as you press
the [PAUSE] key repeatedly.
* The following submenus under the Factory Mode menu will be printed as you press
the [PAUSE] key repeatedly.
* For setting each item, see (3-3)-(a) “Factory Mode menu table”, and setting example
How to change the value in the Factory Mode menu
* For setting each item, see (3-3)-(a) “Factory Mode menu table”, and setting example
How to change the value in the Factory Mode menu” on page 2-46.
Citizen CLP-621 VuePrint Menu System
The four control panel buttons are used to select different options. Generally:
Yes / Select / Save = PAUSE (P) key
No / Next Item / Increase Item = STOP (S) key
Next Digit = FEED (F) key
Exit to previous menu = MODE (M) key
Do you want to reset this printer to factory settings? Yes=(PAUSE) No=(STOP)
Do you want to print the current menu settings? Yes=(PAUSE) No=(STOP)
Do you want to change the menu settings? Yes=(PAUSE) No=(STOP)
Through Sensor Position +000
Save=(PAUSE) Next Digit=(FEED) Change value=(STOP) Exit=(MODE)
Reflect Sensor Position +000
Save=(PAUSE) Next Digit=(FEED) Change value=(STOP) Exit=(MODE)
Mach Tear Position +000
Save=(PAUSE) Next Digit=(FEED) Change value=(STOP) Exit=(MODE)
(
to be continued
)
Do you want to change “Factory Mode Menu” items?
Yes=(PAUSE) No=(STOP) Exit=(MODE)
Note: In the actual printing, the cursor “^” will be printed instead of “
(underline)”.
