The following characters can be output, depending on the characters displayed on the balance :
Normal Operation
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
* * * * + D D D D D D D D D D D D D D D * U U U LF CR
or * * * * - D D D D D D D D D D D D D D D * U U U LF CR
or l l l * + D D D D D D D D D D D D D D D * U U U LF CR
* : Space CR : Carriage Return
D : Digit or letter LF : Line Feed
U : Unit Symbol l : ID code Character
Special Codes
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
- - - - - - - O L - - - - - - LF CR
or - - - - - - - U L - - - - - - LF CR
or - - - - - - - O r - - - - - - LF CR
- - - - - - - L L - - - - - - LF CR
- - - - - - - H H - - - - - - LF CR
OL : Space UL : Carriage Return
Or : Digit or letter LL : Line Feed
HH : Unit Symbol
107
Purpose
Your balance is equipped with an interface port for connection to a computer or other peripheral device.
You can use an on-line computer to change, start and/or monitor the functions of the balance and theapplication programs.
Features
• Type of interface: Serial interface
• Operating mode: Full duplex
• Standard: RS-232
• Transmission rates: 300; 600; 1,200; 2,400; 4,800; 9,600; 19,200 baud 57600
• Parity: Mark, space, odd, even, none
• Character format: 1 start bit, 8-bit ASCII, parity,1 or 2 stop bits
• Handshake: None
• Data output format of the balance : 26 characters
Factory settings:
Transmission rate: 1,200 baud (9600)
Parity: Odd (none)
Stop bits: 1 stop bit
Handshake: None
Print manually/automatically: Manual at
stability
Preparation
• See “Pin Assignments”
108
9. Data Interface
9.1 Output Format with 26 Characters
