Model 2010 Speciﬁcations

Sep 16, 20 10

The Model 2010 appliance is a standard 1U 19 inch rack-mountable appliance that supports up to 500 concurrent users.

The 2010 appliance has the following ports:

Two front-mounted 10/100/1000 Ethernet ports

One RS232 front-mounted serial console port

One rear-facing USB port
