Prerequisites for Installing Access Gateway VPX
Version 5.0 or 4.6
Sep 18, 2012
The following table describes the minimum specifications for the hardware on which the hypervisor— XenServer, VMware
ESX, or VMware ESXi— runs Access Gateway VPX.
Table 1. Minimum Hardware Requirements for the Hypervisor Host
CPU One or more 64-bit x86 CPUs
RAM At least 2 gigabytes (GB)
Disk
space
Locally attached storage (PATA, SATA, SCSI) with minimum of 40 GB of disk space.
General disk space requirements for Access Gateway VPX: XenServer installation creates a 4-GB partition
for the XenServer host control domain; remaining space is available for Access Gateway VPX and other
virtual machines.
Network One 1 Gbps network adapter required; Recommended: Two network adapters of 1 Gbps each
To install XenServer, see the XenServer Installation Guide on the Citrix Support Web site.
To install VMware, see the manufacturer's documentation.
XenServer and VMware must provide adequate virtual computing resources to the Access Gateway VPX as listed in the
following table.
Table 2. Virtual Computing Resources of Access Gateway VPX
Memory 1 GB for Access Gateway VPX 4.6
From 1 up to 4 GB for Access Gateway VPX 5.0
Virtual CPU (VCPU) One VCPU minimum, two VCPUs recommended for better performance. Access Gateway VPX
can support up to eight cores.
Virtual Network
Interfaces
For Access Gateway VPX 4.6, you can use one or two virtual network interfaces.
For Access Gateway VPX 5.0, you can use up to four virtual network interfaces.
Minimum Storage
Requirement
12 GB
