Citrix NetScaler SDX 8015 User Manual

© 1999-2017 Citrix Systems, Inc. All rights reserved. p.109https://docs.citrix.com
The following table lists the settings used in this example:
Entity Name Details
IP address of client CL1 CL1 192.0.2.10
IP address of servers S1 198.51.100.19
S2 198.51.100.20
MTU for interface 10/1 (by using the Management Service interface). 1500
MTU set for interface 10/2( by using the Management Service interface). 9000
MTU for VLAN 10 on NS1 (by using NetScaler command line interface). 1500
MTU set for VLAN 20 on NS1 (by using NetScaler command line
interface).
9000
Services on NS1 representing servers SVC-S1 IP address: 198.51.100.19
Protocol: HT TP
Port: 80
MSS: 8960
SVC-
S2
IP address: 198.51.100.20
Protocol: HT TP
Port: 80
MSS: 8960
