Citrix NetScaler SDX 25100A, SDX 25160A
Jan 11, 2017
The Citrix NetScaler SDX 25100A and SDX 25160A are 2U appliances. Each model has two 10-core processors, 256 GB of
memory, eight 40GE QSFP+ ports (8x40GE QSFP+).
The following figure shows the front panel of the SDX 25100A and SDX 25160A appliance.
Figure 1Figure 1. Citrix NetScaler SDXSDX 25100A and SDX 25160A (8x40GE QSFP+) front panel
The NetScaler SDX 25160A and SDX 25100A appliances have the following ports:
RS232 serial Console Port.
10/100Base-T copper Ethernet Port (RJ45), also called the LOM port. You can use this port to remotely monitor and
manage the appliance independently of the NetScaler software.
Two 10/100/1000Base-T copper Ethernet Management Ports (RJ45), numbered 0/1and 0/2 from left to right. These
ports are used to connect directly to the appliancefor system administration functions.
Network ports, eight 40GE QSFP+ ports (8x40GE QSFP+).
Note the following points regarding the network ports on SDX 25100A and SDX 25160A appliances:
10GE ports do not support 1G copper or 1G fiber transceivers.
40GE ports do not support 10G and 1G transceivers.
The following figure shows the back panel of the SDX SDX 25100A and SDX 25160A appliance.
Figure 2Figure 2. Citrix NetScaler SSDX 25100A and SDX 25160A back panel
