Citrix NetScaler SDX 8015 User Manual

© 1999-2017 Citrix Systems, Inc. All rights reserved. p.12https://docs.citrix.com
1G SFP, 10G SFP, 40G QSFP+
A 1G SFP port can operate at a speed of 1 Gbps. It accepts either a copper 1G SFP transceiver, for operation as a copper
Ethernet port, or a fiber 1G SFP transceiver for operation as a fiber optic port.
The 10G SFP+ and Base-T 10G, 40G QSFP ports are high-speed ports that can operate at speeds of up to 40 Gbps. You
need a fiber optic cable to connect to a port. If the other end of the fiber optic cable is attached to a 1G SFP port, the 10G
SFP+ port automatically negotiates to match the speed of the 1G SFP port.
Port s Compat ibilit yPort s Compat ibilit y
On some appliances, the 10G slot supports coppercopper 1G transceivers, which can operate at up to 1 Gbps in a 10 Gbps slot.
Not e: Not e: Certain platforms have 10G slots that do not support copper transceivers. Check with your account representative
for support details.
Not e:Not e: You cannot insert a fiber 1G transceiver into a 10G slot.
Not e:Not e: You cannot insert a 10G transceiver into a 1G slot.
1G Pluggable Media
The following table lists the maximum distance specifications for 1G transceivers.
T able 3. Copper 1G SFP Dist ance Specif icat ionsT able 3. Copper 1G SFP Dist ance Specif icat ions
SKUSKU Descript ionDescript ion T ransmit t erT ransmit t er
Wavelengt hWavelengt h
(nm)(nm)
CableCable
T ypeT ype
T ypicalT ypical
ReachReach
(m)(m)
Product sProduct s
EW3A0000235,
EW3B0000235,
EW3C0000235,
EW3D0000235,
EW3E0000235,
EW3F0000235,
EW3P0000143,
EW3X0000235,
EW3Z0000087
Citrix
NetScaler 1G
SFP Ethernet
Copper
(100m) - 44
PackPack
n/a Category
5 (Cat-5)
Copper
Cable
100 m SDX 8015/8400/8600, SDX
22040/22060/22080/22100/22120,
SDX 24100/24150
T able 4 . Short Reach Fiber 1G SFP Dist ance Specif icat ionsT able 4 . Short Reach Fiber 1G SFP Dist ance Specif icat ions
SKUSKU Descript ionDescript ion T ransmit t erT ransmit t er
Wavelengt hWavelengt h
(nm)(nm)
Fiber T ypeFiber T ype T ypicalT ypical
ReachReach
(m)(m)
Product sProduct s
EW3A0000234,
EW3B0000234,
EW3C0000234,
EW3D0000234,
EW3E0000234,
EW3F0000234,
EW3P0000142,
Citrix
NetScaler 1G
SFP Ethernet
SX (300m) - 44
PackPack
850nm
(nominal)
50/125um
MMF,
2000MHz-
km (OM3)
550 m SDX 8015/8400/8600, SDX
22040/22060/22080/22100/22120,
SDX 24100/24150
50/125um
MMF,
550 m
