ENGINE
139
CHECKING AND SETTING THE VALVE TIMING
Engines : NFX - NFU
TOOLS
- [1] Belt tension measuring instrument : 4122-T
- [2] Flywheel locating peg : 4507-T.A.
- [3] Camshaft pulley locating peg, exhaust : 4533-T.A. C2
Tool kit 4507-T
- [4] Camshaft pulley locating peg, inlet : 4533-T.A. C1
- [5] Tensioning tool : 4707-T.J.
CHECKING THE VALVE TIMING
- Peg the flywheel using the tool [2].
- Peg the exhaust camshaft pulley [3].
- Peg the inlet camshaft pulley [4].
SETTING THE VALVE TIMING.
- Peg the flywheel using the tool [2].
- Peg the camshaft pulleys [3] and [4].
B1EP11CCB1EP11BC
SAXO - XSARA
