CLUTCH SPECIFICATIONS BERLINGO

Engine type HFX KFW NFU WJY RHY

Gearbox MA/5 BE4/5

Make VALEO LUK

Mécanisme/Type 200 CPX 3850 200 P 4700 235 T 5700

Clutch disc 200 XS L73C 11RX 200 XSL 73 200 228

Ext./Int. lining Ø 200/137 228/155

Disc lining type F808 F408

1.1i 1.4i 1.6i 16V 1.9 D 2.0 HDi
