CITROEN C3 2003 - Tightening Torques Engines 8 HY - 8 HV

76
ENGINE
SPECIAL FEATURES - TIGHTENING TORQUES ( m.daN )
Engines : 8HY - 8HV
RH engine support
Screw (1) 6 ± 0.6
Screw (2) 6 ± 0.6
RH lower engine support
Screw (3) 5.7 ± 0.5
LH upper engine support
Screw (7) 6 ± 0.6
Screw (8) 5.5 ± 0.5
LH lower engine support
Screw (6) 5.4 ± 0.5
Torque reaction rod
Screw (4) 6 ± 0.6
Screw (5) 6 ± 0.6
B1BP2MNP
C3
