373
BRAKES
B3FP06FC
B3FP06GC
BRAKES
Conditions
- Vehicle in running order - 5 litres of fuel.
- A driver (75 Kg).
Adjusting the brake limiter.
- Apply the brake pedal to close the limiter.
- Adjust using the screw (2) to obtain a clearance J of 0.5 to 2 mm.
NOTE : Do not touch (3) which has been adjusted at the factory.
Adjusting the stop lamp switch.
Clearance J = 2 to 3 mm.
After adjustment, tighten the lock nut (1) to 1 m.daN.
SAXO - All Types
