BRAKES
HANDBRAKE (Adjustment)
Prior to adjustment.
- Release the handbrake.
- Drums rotating freely.
- No tight spot (If there is one, check if the primary or secondary cables are
correctly routed).
- Check that all the parts slide and move correctly.
- Bleed the main circuit.
Adjustment.
- Set the brake to the 4th notch.
- Tighten the nut (3) until the rear brakes are applied.
- Check that:
- there is a total travel of between 4 and 7 notches.
- the two secondary cables (1) on the balance lever (2) move together.
- the wheels rotate freely when the brake is released.
- Check that the brake warning lamp comes on from the 4th notch.
NOTE : The handbrake operates on the rear wheels.
B3FP106JC
SAXO - All Types
