230
INJECTION
FITTING BOSCH INJECTORS
Engine :VJX
B1HP0YNC B1HP0YPC B1HP0YGC
Fitting an injector
The copper seal (1) and the
fire seal washer (2) are to be
replaced each time they are
removed.
NOTE : Fitting parts of diffe-
rent makes is PROHIBITED.
WARNING : Ensure that the
fire seal washer (2) is fitted
the right way round.
Tightening of the injector
holder on the cylinder head:
[1] Tool to remove/refit injectors 7007-T
[2] 7008-T Tool kit 4123-T
(3) Tighten lightly to avoid distortion.
Tighten to 7 m.daN.
VJZ
7 m.daN
All Types
9 m.daN
SAXO
