229
INJECTION
ADJUSTING THE MECHANICAL CONTROLS OF THE BOSCH INJECTION PUMP
Engine : VJX (continued)
ANTI-STALL ADJUSTMENT.
- Insert a 1 mm shim [1] between the throttle lever (10) and the residual
output adjustment screw (9).
- Turn the residual output adjustment screw (9) to obtain an engine speed
of: 835 ± 40 rpm.
- Remove the shim [1].
CHECKING THE ENGINE DECELERATION.
- Move the throttle lever (10) to obtain an engine speed of 3000 rpm.
- Release the throttle lever (10).
- The deceleration should be between 2 and 3 seconds.
ESSENTIAL : Check the operation of the manually-operated «STOP»
control (11).
B1HP0HRD
SAXO
