403
BRAKES
XSARA - All TypesREAR BRAKE SPECIFICATIONS
Evolution : Rear brake drum hub 01/1999 #
New assemblyOld assembly
Evolutions.
New components : Rear wheel stub. - Stop ring (ref. (4)). - Double shouldered washer (ref. (5))
NOTE : The new assembly is identified by a figure from 1 to 6 cold-stamped on the head of the wheel stub at «a».
(1) Washer exterior diameter = 38 mm
.
(2) Stop ring
(3) Circlip.
NOTE : This assembly is equipped with either part (2) or part (3).
Ref. «a»: Figure from 1 to 6 cold-stamped.
(4) Stop ring.
(5) Double shouldered washer, exterior diameter = 48 mm.
B3FP11ADB3FP119D
