227
INJECTION
SAXO
ADJUSTING THE MECHANICAL CONTROLS OF THE BOSCH INJECTION PUMP
ADJUSTING THE FAST IDLE SPEED.
- Bring the lever (3) into contact with the screw (2).
- Use the screw (2) to obtain the fast idle speed : 1100 ± 100 rpm.
Engine cold.
- Ensure that the lever (3) is up against the screw stop (2).
- If not, slightly tension the cable (4) using the cable clamp (1).
- Finish tensioning with the sheath tensioner (5).
Engine hot.
- Ensure that the cable (4) is slack.
- Check the operation of the thermostatic sensor on the coolant outlet housing : there should be a minimum
6 mm cable travel between a cold and a hot engine.
- If not, replace the thermostatic sensor. Tighten to 2.5 m.daN.
B1HP0HQC
Engine : VJX
B1HP0HUC
