AXLES
SUSPENSION
STEERING
XSARA - All TypesFRONT AXLE
Tightening torques (m.daN).
(1) Damper nut
(2) Cup screw
(3) Suspension leg
(4) Anti-roll bar link rod upper ball-joint
(5) Suspension leg pivot (hollow pivot)
(5) Suspension leg pivot (pivot «H»)
(6) Anti-roll bars
(7) Anti-roll bar link rod lower ball-joint
(8) Pivot lower ball-joint
(9) Driveshaft nut
(10) Wheel bolt
(11) Lower arm front mounting
(12) Lower arm rear mounting and anti-roll
bar bearing
(13) Screw under rear mounting
(14) Ball-joint fixing on lower arm
Subframe to bodyshell fixing screw
4.5 ± 0.4
2.5 ± 0.3
3.7 ± 0.3
4.5 ± 0.5
5.5 ± 0.5
3.7 ± 0.3
4 ± 0.4
32.5 ±2.5
9 ± 1
7.6 ± 0.7
6.8 ± 0.6
3.1 ± 0.3
5± 0.5
8.5 ± 0.8
B3CP040P B3CP041D
Vehicles RPO 8667 # are all equipped
as standard with ventilated discs.
