CITROEN C3 2003 - Page 365

361
AXLES
SUSPENSION
STEERING
A> B =Negative figure: – = TOE-OUT
A < B = Positive figure: + = TOE-IN
WARNING
AXLE GEOMETRY
Measurements at reference height (continued). Compress the suspension to obtain the calculated values.
Vehicle All Types
Front axle Rear axle
Vehicle Tracking Castor Pivot angle Camber Tracking Camber
Adjustable Yes No
All Types
0 ± 1mm 4.8 mm ± 1mm
- 0°09’ à +0°09’
3° ± 18’ 10° 43’ ± 30’’ 0° ± 30’
- 0° 43’ ± 0° 09’
- 1°13’ ± 18’
Vehicle All Types CRD (Condition de route difficile)
Front axle Rear axle
Vehicle Tracking Castor Pivot angle Camber Tracking Camber
Adjustable Yes No
All Types
- 1 ± 1mm 3.8 mm ± 1mm
- 0°18’ à 0°0’
2°56’ ± 18’ 10°25’ ± 30’ 0°07’ ± 30’
- 0°34’ ± 0° 09’
- 1°14’ ± 18’
NOTE : When checking axles, the vehicle should be at reference height.
(*) = Fuel tank full.
XSARA PICASSO - All Types
All Types
Unladen (*)
150 mm (Minimum value)
Ground clearance
