364
AXLES
SUSPENSION
STEERING
REAR AXLE
Evolution :
- New rear hub nut (3).
- Washer discontinued (2).
Old fitting (A)
(1) Rear hub nut.
(2) Thrust washer.
ESSENTIAL : Tighten to : 27,5 ± 2,7 m.daN
New fitting (B)
(3) Rear hub nut.
ESSENTIAL : Tighten to : 25 ± 2,5 m.daN.
NOTE : It is possible to have both types of fitting on the same axle.
The old nut (1) requires the fitting of the thrust washer (2).
WARNING : do not fit a thrust washer (2) with a new nut (3).
ESSENTIAL: Respect the tightening torque to be applied when fitting.
WARNING : Identify the type of fitting, before starting a repair.
B3DP08AD
Evolution : Rear hub nut
Old # 15/12/1999. New 15/12/1999 #
XSARA PICASSO - All Types
