369
AXLES
SUSPENSION
STEERING
Steering rack
Rack pinion
Number of teeth Number of steering Turning circle Turning circle
travel in rack wheel turns between walls between kerbs
Left hand drive
71.7x2
LH helix
28 teeth 3.22 12 m 11.48 m
Right hand drive RH helix
Motorisation Steering valve
NFV - 6FZ - RFN - RHY Number of teeth : 7
Length of the steering link rods (pre-adjustment):
- Between ball-joint centres = 392 mm
- Between the centre of the pivot ball-joint and the contact face of the steering rack ball-joint = 412 mm.
STEERING SPECIFICATIONS
XSARA PICASSO - All Types
