BRAKES
CHECKING AND ADJUSTING THE LOAD-SENSITIVE BRAKE COMPENSATOR
Adjusting the load-sensitive brake compensator
- Untighten the screw (1).
- Move the spring rod.
- Decrease the length of the spring to increase the pressure.
- Increase the length of the spring to decrease the pressure.
- Tighten the screw (1) to 1,2 ± 0,25 m.daN.
- Check the brake pressure.
After the operation :
- Remove the checking tool [1].
- Bleed the braking circuit (see corresponding operation).
- Carry out a road test.
XSARA PICASSO - All Types
B3FP13VC
