478
XSARA PICASSO DW10
AIR CONDITIONING SYSTEM R 134.a
Checks on the air conditioning circuit
Key.
T/P = Scale of:
- Temperature (°C), average of air from the central vents.
- Pressure, High (Bars).
- Pressure, Low (Bars).
Te = Exterior temperature (°C).
HP = Pressure at compressor outlet (Bars).
Ta = Temperature (°C) of air blown from the vents.
BP = Pressure at compressor inlet (Bars).
C5HP14ZD
AIR
CONDITIONING
