ENGINES
SPECIAL FEATURES: TIGHTENING TORQUES
Cylinder block
22 Crankshaft bearing cap sealing screw 1 ± 0,1
Con rod cap screw (*)
23 Pre-tightening 1
Tightening 2,3 ± 0,1
Angular tightening 46° ± 3°
24 Knock sensor 2 ± 0,5
Accessories drive belt pulley screw
25 Tightening 4 ± 0,4
Angular tightening 80° ± 5°
Engine: RFK
B1DP1KTP
(*) = IMPERATIVE: Respect the tightening sequence (see following page).
