259

INJECTION

AIR SUPPLY CIRCUIT SPECIFICATION

B1HP22PD

(1) Air filter assembly

(2) Oil trap

(3) Turbocharger resonance attenuator

(4) Turbocharger

(5) Air/air exchanger

(6) Air metering device

(7) Air distributor

Air filter : MARK 4

Turbocharger : MHI TD025S2

Engine: 9HX
