AXLES
SUSPENSION
STEERING
GENERAL SPECIFICATIONS: POWER-ASSISTED STEERING
The degree of steering assistance varies as a function of the following parameters:
- The speed of the vehicle.
- The speed of rotation of the steering wheel.
Power steering oil : TOTAL FLUIDE LDS H 50126.
Quantity of oil in the power steering circuit :0,85 Litre.
Checks.
Checking the level of power steering fluid is by means of the gauge cap at «c».
Ref. Description
12 Power steering mechanism with integral ram
13 Distributor valve
14 Steering oil radiator fitted in the front panel (only in driving school version)
15 Power steering electropump, installed on the front RH chassis member
16 Power steering oil reservoir
17 High pressure pipe
18 Low pressure pipe
B3EP16RD
Steering assistance circuit
