TIGHTENING TORQUES: POWER-ASSISTED STEERING

Steering assistance electrovalve

Ref. Description Tightening

15 Fixing of electrovalve on chassis member 2,3 ± 0,2

16 Screw fixing bracket on electrovalve 2 ± 0,2

17 Fixing of electrovalve on chassis member 2,2 ± 0,2

B3EP178D
