349

AXLES

SUSPENSION

STEERING

GENERAL SPECIFICATIONS: POWER-ASSISTED STEERING STEERING

Reference Description

1 Driver’s airbag

2 Controls on the steering wheel

3 Fixed central controls steering wheel

4 Steering wheel angle sensor

5 Controls on the steering wheel

6 Ignition / steering lock

C5FP0QQD

UK-C4-page322-360-2004 15/11/04 9:07 Page 349
