287

CLUTCH

GEARBOX

DRIVESHAFTS

MA/5 GEARBOX CONTROLS

Engines: KFU - NFU

Unlocking a sleeve stop.

Press on the tabs of the clip (6) at «b», using a small flat screwdriver.

Disengage the sleeve stops from their supports by pulling upwards.

B2CP3ZFD

UK-C4-page271-321-2004 15/11/04 9:15 Page 287
