286

CLUTCH

GEARBOX

DRIVESHAFTS

MA/5 GEARBOX CONTROLS

Engines: KFU - NFU

Length A (mm)

Gear engagement control cable 791,2 ± 2

Length B (mm)

Gear selection control cable 791,2 ± 2

NOTE: The gear engagement cable has a black colour identification on

the sleeve stop at «a».

Gear selection and engagement control cables

B2CP3ZDD

B2CP3ZEC

UK-C4-page271-321-2004 15/11/04 9:15 Page 286
