CITROEN C4 2004 - Deflation Detection System

334
AXLES
SUSPENSION
STEERING
WHEEL AND TYRES
Deflation detection system (according to trim level)
(4) Valve (8) Seal
(5) Antenna (9) Cap
(6) HF transmitter unit (10) Nut
(7) Washer
Composition.
A SIEMENS HF transmitter module (6) integral to each wheel in the place of the valve, each
including a lithium battery.
An HF receiver in the communication module under the dashboard.
WARNING: Each time a tyre is replaced, it is necessary to replace the valve (4).
WARNING: Each time a wheel rim is replaced, it is necessary to replace the seal (8).
WARNING: Each time a transmitter module is changed, it is necessary to have the replacement
recognised by the deflation detection ECU, using a diagnostic tool.
B2GP01GD
