350

AXLES

SUSPENSION

STEERING

GENERAL SPECIFICATIONS: POWER-ASSISTED STEERING

[1] Tool for locking the fixed central controls steering wheel : 9702-T

WARNING: The mechanism of the fixed central controls steering wheel cannot be dismantled.

C5FP0QRC

Fixed central controls steering wheel

UK-C4-page322-360-2004 15/11/04 9:07 Page 350
