CITROEN C4 2004 - Front Axle

337
AXLES
SUSPENSION
STEERING
A < B = Positive figure: + = TOE-IN
A > B = Negative figure: - = TOE-OUT
WARNING
AXLE GEOMETRY
Front axle
Dissymmetry of lower castor at 0° 30’.
Dissymmetry of lower camber 0° 30’.
Distribute symmetrically, LH / RH wheel, the total tracking value.
Engines
KFU - NFU RFJ - RFN RFJ - RFN - RFK
9HX - 9HY - 9HZ 9HX - 9HY - 9HZ
RHR
9HX - 9HY - 9HZ - RHR
Tyres 195/65 R 15 205/55 R 16 205/50 R 17
Camber
(± 0° 30’)
0°
Castor
(± 0° 30’)
Non adjustable 5° 5° 09’ 5° 12’
Pivot angle
(± 0° 30’)
11° 41’
Tracking Adjustable
- 2,5 ± 1 mm
- 0° 23’ ± 0° 09’ - 0° 21’ ± 0° 09’ - 0° 20’ ± 0° 08’
NOTE: Front of the vehicle (following arrow).
